Ready to Assemble DIY CNC

Raptor 30

Raptor 30 3

Profile  Rails/Blocks 20mm

16/20mm Precision Ballscrews

All machined 3/4" in aluminum

Cutting Area

X 30" up to 42"

Y 24"

Raptor 30

Ready to Assemble DIY CNC

Predator

predator 1

Profile Rails/Blocks 25mm

25mm Precision Ballscrews

All machined 1"  aluminum

Cutting Area

X 30" up to 54"

Y 25" or 37"

Predator

Ready to Assemble DIY CNC

Mini Raptor

Mini dem 6

Profile Rails/Blocks 15mm

16/20mm Precision Ballscrews

All machined 3/4" in aluminum

Cutting Area

X 18" up to 42"

Y 12"

Mini Raptor

Resolution

(smallest movement):

0.000062" (with 16 microsteps and 5mm pitch screw)

0.000123" (with 16 microsteps and 10mm pitch screw)

 0.000307" (with 16 microsteps and 25mm pitch screw)



Repeatability

(ability to return to the same position):

0.0008" or better

Rapid Speeds

100-300ipm (with 5mm pitch screw - varies with axis length, spindle mass and stepper motor combination)
200-600ipm (with 10mm pitch screw - varies with axis length, spindle mass and stepper motor combination)

500-1200ipm (with 25mm pitch screw - varies with axis length, spindle mass and stepper motor combination)

Custom Aluminum Profile

80x80mm Custom Aluminum Profile with rail support for  Raptor  and  Predator

I Guess this is where you should have info on why you should look at XZero !!! But will just let the machines do the talking!!!

Precision Machined Frame

  • Air-craft grade Aluminum
  • 3/4 to 1 Inch
  • Pockets / Pins for easy set up
  • Machined Flat all mounting area

Precision Components

  • 16mm to 25mm OD .
  • Pitch from 5mm to 25mm
  • 4-Way-equal load blocks
  • Profile Rails
  • Double Row Angular contact bearings

Custom Aluminum Profile

  • Raptor 30 / Predator
  • Custom Aluminum Profile 80x80mm
  • Support ledge for 20/25mm profile rails
  • Machined Ends Flat

Thanks to Bob at  DZ custom cues
